raygeo.image
Image processing functions for laser cutting applications.
Provides sRGB/linear color space conversions, RGBA-to-grayscale/binary conversions with alpha unpremultiplication, grayscale normalization with auto-levels, and dithering algorithms (Floyd-Steinberg, Bayer, minimum run length) for converting grayscale images to binary output.
Functions
apply_bayer_dither()
apply_bayer_dither(grayscale: numpy.NDArray[numpy.uint8], bayer_matrix: numpy.NDArray[numpy.float32], invert: bool, cell_size: int = 1) -> numpy.NDArray[numpy.uint8]
Apply ordered (Bayer) dithering using a threshold matrix.
Returns: 2D binary uint8 array (values 0 or 1).
| Parameter | Type | Description |
|---|---|---|
grayscale | numpy.NDArray[numpy.uint8] | 2D grayscale image as uint8 array. |
bayer_matrix | numpy.NDArray[numpy.float32] | 2D Bayer threshold matrix as float32. |
invert | bool | If True, invert the output. |
cell_size | int = 1 | Pixel grouping size for the threshold. |
| Returns | numpy.NDArray[numpy.uint8] |
apply_floyd_steinberg_dither()
apply_floyd_steinberg_dither(grayscale: numpy.NDArray[numpy.uint8], invert: bool) -> numpy.NDArray[numpy.uint8]
Apply Floyd-Steinberg error-diffusion dithering.
Returns: 2D binary uint8 array (values 0 or 1).
| Parameter | Type | Description |
|---|---|---|
grayscale | numpy.NDArray[numpy.uint8] | 2D grayscale image as uint8 array. |
invert | bool | If True, invert the output (swap black/white). |
| Returns | numpy.NDArray[numpy.uint8] |
apply_minimum_run_length()
apply_minimum_run_length(binary: numpy.NDArray[numpy.uint8], min_run_length: int) -> numpy.NDArray[numpy.uint8]
Remove binary runs shorter than the given minimum.
Returns: 2D binary uint8 array with short runs removed.
| Parameter | Type | Description |
|---|---|---|
binary | numpy.NDArray[numpy.uint8] | 2D binary uint8 array (values 0 or 1). |
min_run_length | int | Minimum run length to keep. |
| Returns | numpy.NDArray[numpy.uint8] |
compute_auto_levels()
compute_auto_levels(gray_image: numpy.NDArray[numpy.uint8], clip_percent: float = 1) -> tuple[int, int]
Compute auto black/white levels from a grayscale image histogram.
Returns: Tuple of (black_point, white_point).
| Parameter | Type | Description |
|---|---|---|
gray_image | numpy.NDArray[numpy.uint8] | Grayscale image as uint8 array. |
clip_percent | float = 1 | Percentage of pixels to clip from each end. |
| Returns | tuple[int, int] |
linear_to_srgb()
linear_to_srgb(array: numpy.NDArray[numpy.float32], dither: bool = False) -> numpy.NDArray[numpy.uint8]
Convert linear light values to sRGB pixel values.
Returns: Array of sRGB uint8 values with the same shape.
| Parameter | Type | Description |
|---|---|---|
array | numpy.NDArray[numpy.float32] | Input array of linear float32 values in [0, 1]. |
dither | bool = False | Apply dithering to reduce banding artifacts. |
| Returns | numpy.NDArray[numpy.uint8] |
normalize_grayscale()
normalize_grayscale(gray_image: numpy.NDArray[numpy.uint8], black_point: int = 0, white_point: int = 255) -> numpy.NDArray[numpy.uint8]
Normalize a grayscale image by stretching the dynamic range.
Returns: Normalized grayscale image with the same shape.
Raises: ValueError — If black_point >= white_point.
| Parameter | Type | Description |
|---|---|---|
gray_image | numpy.NDArray[numpy.uint8] | Input grayscale image as uint8 array. |
black_point | int = 0 | Black point for normalization. |
white_point | int = 255 | White point for normalization. |
| Returns | numpy.NDArray[numpy.uint8] |
rgba_to_binary()
rgba_to_binary(rgba: numpy.NDArray[numpy.uint8], width: int, height: int, stride: int, threshold: int = 128, invert: bool = False) -> numpy.NDArray[numpy.uint8]
Convert raw BGRA pixel buffer to binary image using thresholding.
Transparent pixels (alpha == 0) are always treated as white (0).
Returns: 2D binary uint8 array (values 0 or 1) with shape (height, width).
| Parameter | Type | Description |
|---|---|---|
rgba | numpy.NDArray[numpy.uint8] | Flattened uint8 buffer of shape (stride * height * 4,). |
width | int | Image width in pixels. |
height | int | Image height in pixels. |
stride | int | Row stride in pixels. |
threshold | int = 128 | Brightness value (0-255) for binarization. |
invert | bool = False | If True, pixels above threshold become black (1). |
| Returns | numpy.NDArray[numpy.uint8] |
rgba_to_grayscale()
rgba_to_grayscale(rgba: numpy.NDArray[numpy.uint8], width: int, height: int, stride: int) -> tuple[numpy.NDArray[numpy.uint8], numpy.NDArray[numpy.float32]]
Convert raw BGRA pixel buffer to grayscale with alpha unpremultiplication.
Performs proper unpremultiplication of alpha and blends to white background for grayscale calculation using BT.601 luminance weights.
Returns: Tuple of (grayscale_uint8, alpha_float32) arrays, each (height, width).
| Parameter | Type | Description |
|---|---|---|
rgba | numpy.NDArray[numpy.uint8] | Flattened uint8 buffer of shape (stride * height * 4,). |
width | int | Image width in pixels. |
height | int | Image height in pixels. |
stride | int | Row stride in pixels (may be larger than width). |
| Returns | tuple[numpy.NDArray[numpy.uint8], numpy.NDArray[numpy.float32]] |
rgba_to_grayscale_inplace()
rgba_to_grayscale_inplace(rgba: numpy.NDArray[numpy.uint8], width: int, height: int, stride: int) -> None
Convert raw BGRA pixel buffer to grayscale in place.
Modifies the buffer directly, converting BGR channels to grayscale while preserving the alpha channel.
| Parameter | Type | Description |
|---|---|---|
rgba | numpy.NDArray[numpy.uint8] | Flattened uint8 buffer of shape (stride * height * 4,). |
width | int | Image width in pixels. |
height | int | Image height in pixels. |
stride | int | Row stride in pixels. |
| Returns | None |
srgb_to_linear()
srgb_to_linear(array: numpy.NDArray[numpy.uint8]) -> numpy.NDArray[numpy.float32]
Convert sRGB pixel values to linear light values.
Returns: Array of linear float32 values with the same shape.
| Parameter | Type | Description |
|---|---|---|
array | numpy.NDArray[numpy.uint8] | Input array of sRGB uint8 values. |
| Returns | numpy.NDArray[numpy.float32] |
